Flopack Flow Wrapping Machine
On-edge flow wrapping with integrated automatic feeding. Two models, 180 and 230 packs per minute.
Overview
Flopack is an on-edge horizontal flow-wrapping machine with an integrated automatic feeding system, built in two models. The FLOWPACK-230 is the flagship of the range at up to 230 packs per minute. The FLOWPACK-180 runs up to 180 packs per minute and is where most lines start. Both wrap on edge, which suits stacked biscuits and similar products that must not be handled flat, and on both a double cutter mechanism and positive wrapper feed form the sealed film pack. How much of the rest is automated is a choice rather than a fixed list. Servo-driven index conveyors and product pushers, PID temperature control through the PLC, and continuously adjustable speed from a variable frequency drive can all be fitted, and which of them a given machine carries depends on the model and how it is specified. The FLOWPACK-180 is built simpler by default. Send us your throughput and pack size and we will confirm the model and exactly what it includes.
Two models
Same machine, two outputs. Tell us the throughput and pack size you need and we will quote the one that fits.
The flagship, and the fastest wrapper in the range. Specified to suit the line it goes into.
The entry point into the range, and where most lines start. Built simpler by default. Specification table and brochure below.
Key Specifications
Full Technical Specifications
Flopack Flow Wrapping Machine: complete specification details
| Specification | Value |
|---|---|
| Max Output | 180 packs/min on the FLOWPACK-180 (depending on packet size) |
| Product Length | 60 – 200 mm |
| Product Width | 40 – 75 mm |
| Product Height | 50 – 70 mm |
| Width + Height | < 125 mm |
| Wrapper Cut-Off Length | 120 – 250 mm |
| Max Reel Width | 280 mm |
| Max Reel Diameter | 340 mm |
| Reel Core Diameter | 75 mm |
| Machine Dimensions | 5800 × 1600 × 1800 mm (L × W × H, approx.) |
| Machine Weight | 1800 kg (approx.) |
Features & Benefits
Two models: the FLOWPACK-230 flagship at 230 packs/min and the FLOWPACK-180 at 180 packs/min, so the line is sized to the output you need
Double cutter mechanism with positive wrapper feed on both models
Fitted to suit the model and the specification, not standard on every machine: servo-driven index conveyors and product pushers, PID temperature control through the PLC, and a variable frequency drive for continuously adjustable speed
Built and supported by MOI Engineering with spare parts and service
This Machine Is for You If...
You are set up for flow wrapping
You also run individual product wrapping
You need up to 230 packs/min and a machine built to hold that rate
Frequently Asked Questions
Which Flopack model should I choose?
The FLOWPACK-230 if you need the output, the FLOWPACK-180 if you do not. They do the same job at different speeds, so the deciding number is your packs per minute at peak, not your average. Send us that and your pack size and we will say which one fits.
What is the output of each model?
FLOWPACK-180 runs up to 180 packs per minute and FLOWPACK-230 up to 230, both depending on packet size. The FLOWPACK-230 is the flagship of the range.
What product sizes does the Flopack handle?
The published figures are the FLOWPACK-180's: length 60 to 200 mm, width 40 to 75 mm, height 50 to 70 mm, with width plus height under 125 mm, and a machine weight of about 1,800 kg. Send us your product and pack dimensions and we will confirm what the model you are considering will take.
Is the Flopack a flow wrapper or an overwrapper?
A horizontal flow wrapper, and it wraps on edge. It forms a sealed pillow pack around the product rather than folding a sheet around a formed pack, which is what suits stacked biscuits and similar items that should not be handled flat.
What does a Flopack cost?
It depends on the model, the tooling for your pack size, and the options you take, so there is no single figure worth quoting. Send your throughput, product dimensions and wrapper material and you will have a configured price, not a range.
Which model does the downloadable brochure cover?
The FLOWPACK-180. For the FLOWPACK-230, tell us what you need to run and we will put the figures in your quotation.
What is fitted as standard and what is optional?
Both models wrap on edge with a double cutter mechanism and positive wrapper feed. Beyond that it depends on the model and how the machine is specified: servo-driven index conveyors and product pushers, PID temperature control through the PLC, and a variable frequency drive for continuously adjustable speed can all be fitted, and the FLOWPACK-180 is built simpler by default. We would rather confirm your build in writing than have you assume something is included.
