PM4 High-Speed Filter Rod Maker
High-speed rod production: 2,500 per minute.
Overview
The MOI PM4 is a high-speed, fully automatic filter rod making machine designed to produce up to 2,500 filter rods per minute. It integrates a dedicated tow-processing unit via an extension shaft for synchronized formation. Built with variable speed drives (VFD) and PLC controls, it ensures excellent rod density uniformity, consistent cut length, and minimal dusting.
Key Specifications
Full Technical Specifications
PM4 High-Speed Filter Rod Maker -- Complete specification details
| Specification | Value |
|---|---|
| Output Capacity | Up to 2,500 rods per minute (70 mm) |
| Rod Speed | 175 m/min (max) |
| Maximum Cut-Off Speed | 2,500 cuts/min |
| Rod Length Range | 52-120 mm |
| Rod Diameter Range | 5.0-9.0 mm |
| Power Supply | 415V, 3-phase, 50 Hz |
| Power Requirement | 5 kW |
| Machine Dimensions | 2360 × 2360 × 1295 mm |
| Weight | Approx. 1,700 kg |
Features & Benefits
Produces 2,500 filter rods per minute with high consistency and low rejection rates
Dedicated tow processing unit driven mechanically ensuring perfect synchronization
2K single-knife cut-off system ensures clean, accurate cuts at high speeds
Expander tape drum and 3-folder garniture for stable rod formation
Electronic monitoring sensors detect rod break-outs and Ensure safety
This Machine Is for You If...
You need high-speed tobacco rod production for Tobacco Industry production
You're upgrading from manual processes to automated plug manufacturing for cigarette assembly
You need a machine that delivers produces 2
How It Works
- 1
Cellulose-acetate filter tow is opened and conditioned, with plasticiser added for bonding.
- 2
The conditioned tow is gathered and shaped into a continuous filter rod inside a garniture and wrapped in plug-wrap paper.
- 3
The wrap seam is sealed.
- 4
The continuous rod is cut into multiple-length filter rods.
- 5
Finished rods are delivered to a catcher, tray-filler or conveyor to feed downstream tippers.
The PM4 belongs to the Molins PM (“Plug Maker”) filter-rod machine family — the upstream machine that forms the filter rods a tipping unit needs. MOI builds on this proven lineage.
Frequently Asked Questions
What filter material does it run?
Cellulose-acetate tow as standard; paper-type filter material on variants built for it.
Where does it sit in the line?
Upstream — it makes the filter rods that a plug assembler / tipper attaches to tobacco rods on a filter-cigarette line.
How are finished rods handled?
Delivered to a hand catcher, automatic tray filler, or conveyor for downstream use.
